Combine for corn model 4YZB-4

Model

4YZB-4

Design

Wheeled self-propelledintegrated

Strings

4

Line spacing (mm)

530/600

Dimension

Length (mm)

6800

Width (mm)

2800

Height (mm)

3550

Engine

Rated power（kw）

103/113

Adapt to line spacing（mm）

450-580/550-650

Roll Form for Pullingrod

Hexagonal

Formrollto collectcorn

slab

Formskinning roll

Combination of rubber and semi-rubber iron rolls

Poppy. Height forcollectioncorn (mm)

2010

Min. Ground clearance (mm)

≥310

Straw chopper design

Butterfly knife

Gear box type

Mechanical + hydraulic stepless speed change

Wheel size

Guide wheel

10.0/75-15.3

drive wheel

15-24

Terteric working capacity (km/h)

2.0-5.0

Fuel consumption per unit area（kg/nm²）

≤35

Wayunloading

Hydraulic tipping

Return to field system

Central1JH-2000/1JH-2200

conveyor system

Central
